Rockford Fosgate Punch P1S2-10 – 10″ Subwoofer 500 Watts 2-Ohm

Rockford Fosgate Punch P1S2-10 – 10″ Subwoofer 500 Watts 2-Ohm

£101.99

Specifications:

  • Linear spider with embedded 16 AWG tinsel leads
  • High-temp voice coil with spun-laced Nomex® re-inforcement collar
  • Kevlar fiber reinforced paper cone
  • StampCast basket with integrated spider venting
  • Soft touch ABS trim ring with optional grille
  • Custom 10-AWG nickel plated push terminals
  • Extended pole piece and bumped vented backplate
  • Protective PVC textured magnet cover
  • Size: 10″
  • Nominal Impedance: 2-Ohm
  • Power Handling: 250 Watts RMS / 500 Watts Max
  • Voice Coil Diameter: 2.0″ (51.6mm)
  • Magnet Weight: 45 oz. (1.28 Kg.)
  • Speaker Connector: 10 AWG compression
  • Fs (Hz): 30
  • Re (Ohms): 3.6
  • Le (mH): 2.81
  • Qms: 3.00
  • Qes: 0.61
  • Qts: 0.52
  • Vas (Liters): 40
  • Sd (cm2): 370
  • SPL (dB @ 1w/1m): 85
  • Xmax (mm): 9.0
  • Woofer Displacement: 0.13 cu. ft. (3.60 Liters)
  • Cutout Diameter: 9.14 in. (232 mm)
  • Mounting Depth: 5.33 in. (135.4mm)
  • Shipping Weight: 10.9 Lbs. (4.94 Kg.)
Category:

Description

Rockford Fosgate P1 10” is the first in a family of famous “Punch” subwoofers. The P1S2-10 features a 2-Ohm voice coil, 250 Watts RMS power handling, and can accommodate a grille insert using the included soft touch ABS trim ring.



Additional information

Brand

Rockford Fosgate
