- Number of Channels 1
- Rated Power (RMS Continuous Power):
- 300 Watts x 2 @ 4-Ohm
- 500 Watts x 2 @ 2-Ohm
- 1000 Watts x 1 @ 4-Ohm Bridged
- Total Power (Sum of Rated Power): 1000 Watts RMS
- Dynamic Power (PVC/PowerCube® Measurement):
- 401 Watts x 2 @ 4-Ohms 0° Res
- 656 Watts x 2 @ 2-Ohms 0° Res
- Bridgeable: Yes
- Efficiency (average):
- 69% @ 4-Ohm
- 64% @ 2-Ohm
- Total Harmonic Distortion:
- 4-Ohm: <1.0%
- 2-Ohm: <1.0%
- Crossover Controls:
- High-Pass/Low-Pass (HP/LP): 50Hz-250Hz 12dB/octave Butterworth
- Tone Controls:
- Punch EQ2 Bass: 0dB to 18dB @ 45Hz and/or
- Punch EQ2 Treble: 0dB to 12dB @ 12.5kHz
- Function depends upon LP/AP/HP switch position
- Signal Input: Low level: Hi/Low level: 1 RCA pair
- Signal Output Low level: Low level: 1 RCA pair
- Power Input Connector: Captive C-Clamp
- Power Wire Gauge: 4 AWG
- Speaker Output Connector: Captive C-Clamp
- Speaker Wire Gauge: 8 AWG to 18 AWG
- Heat Sink Type: Cast aluminum
- Cooling: Convection
- Remote Controls: Optional Punch Level Control (PLC2) Ready
- Visual Indicators:
- Power/Protect/Thermal LED
- Input Clip LED
- Output Clip LED
- Circuit Topology Class: Class A/B
- Frequency Response: 20Hz to 250Hz /- 1.0dB
- Shipping Weight: 15 Lbs. (6.80 Kg.)
- Dimensions (HxWxL): 2.38 x 7.76 x 15.03 (in) 6.05 x 19.71 x 38.18 (cm)
